DEHN BXTML2BDHFEX6 Lightning Current Arrester 1kA 4.8A 6V 100MHz 12mm W 51mm D 45mm H Polyamide Blue IP20

Product Code: BXTML2BDHFEX6

  • Compact design: 12mm width
  • Wide temp range: -40 to 80°C
  • High protection: IEC/EN 61643-21 compliant
  • Suitable for Blitzductor XT systems
  • Lightweight at only 20g
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester Module
Brand
DEHN
Series
BLITZDUCTOR XT
Application
For protecting one pair of intrinsically safe circuits and galvanically isolated RS485 bus systems

Electrical

No. of Lines/Pairs
1 pair
Nominal Voltage
6V
Voltage Protection Level Up
20V
Nominal Discharge Current Inom (8/20µs)
10kA
Max. Continuous Operating Voltage
4.2 V AC / 6 V DC

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
