Specifications

Product Type Fuse Terminal Block	Brand CONNECTWELL	Series CF
Application Electrical and control circuits requiring fuse protection

Function Single Level Fuse	Rated Current 6.3 A	Rated Voltage 800 V
Terminal Type Screw Clamp Terminal

Cable Cross Section 0.2–4 mm²	Colour Grey	Material Polyamide
Mounting DIN 32/DIN 35/DIN 35-15 Rail	Tightening Torque 0.5 Nm

Depth 57 mm	Height 50.3 mm	Weight 14.7 g
Width 8 mm

Connectwell CF4U Single Level Fuse Terminal Block Screw Clamp Terminal Single Level Fuse 0.2-4sq-mm 800V 6.3A Grey
