BD Sensors 140100413M102002041 Pressure Transmitter

Product Code: 140100413M102002041

  • Thinfilm sensor with 4-20 mA output
  • High accuracy of 0.35% FSO
  • Operates in -40 to 125°C range
  • Rated for up to 1000 bar pressure
  • Fast response time under 5 ms
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Pressure Transmitter
Brand
BD SENSORS
Series
DMP 334

Electrical

Output Signal
4-20mA
Electrical Connection
Male plug M12x1 (4-pin) / metal
Input Signal
1000 bar

Mechanical

Material
stainless steel 1.4542 (17-4 PH)
Mechanical Connection
G1/2" EN 837

Dimensions & Physical Data

Weight
approx. 240g

Environmental

IP Rating
IP67
Ambient Temperature
-40°C to 85°C

Documents

IPD Product Catalogue V17
