ADLER A942450B00 Cartridge Fuse 45 A 1500VDC 22mm Dia x 58mm Fuse Ferrule Terminal For: BH400 BH401 Fuse Holder

Product Code: A942450B00

  • Rated for 45 A, 1500 VDC applications
  • Compatible with BH400, BH401 holders
  • Low power loss of 9 W
  • Ferrule terminal type for secure connection
  • Interrupt rating of 10 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Photovoltaic Fuse Link
Brand
ADLER
Series
A94 gPV
Application
PV combiner boxes, inverters and high-power PV applications

Electrical

Utilization Category
gPV
Breaking Capacity
10kA at 1500V DC
Rated Current (In)
45A
Rated Voltage (Ur)
1500V DC

Mechanical

Body Style
Cylindrical / cartridge
Indicators
without indicator
Material
Glass-fiber body; silver-plated caps
Mounting
BH400 base / cartridge mounting
Size Code
22 x 58
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
58mm
Weight
0.05kg
Width
Ø 22mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-19; IEC 60269-6

Documents

IPD Product Catalogue V17
