ADLER A852250B00 Cartridge Fuse 25 A 1500VDC 10mm Dia x 85mm Fuse Ferrule Terminal For: BH300-01 BH300-02 Fuse Holder

Product Code: A852250B00

  • Rated for 25 A, 1500 VDC
  • Compatible with BH300-01/02 holders
  • High interrupt rating of 30 kA
  • Ferrule terminal type for secure connection
  • Compact design at 85 mm length
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Photovoltaic Fuse Link
Brand
ADLER
Series
A85 gPV
Application
PV combiner boxes, inverters and battery charge controllers

Electrical

Utilization Category
gPV
Breaking Capacity
30kA at 1500V DC
Rated Current (In)
25A
Rated Voltage (Ur)
1500V DC

Mechanical

Body Style
Cylindrical / cartridge
Indicators
without indicator
Material
Glass-fiber body; silver-plated caps
Mounting
BH300-01 fuse holder / cartridge mounting
Size Code
10 x 85
Connection/Termination
Ferrule end caps

Dimensions & Physical Data

Length
85mm
Weight
0.01kg
Width
Ø 10mm

Safety, Standards & Compliance

Standards and Approvals
UL 248-19; IEC 60269-6

Documents

IPD Product Catalogue V17
