ABB TSR20P Safety Relay 24VDC

Product Code: TSR20P

  • Operates at 24 VDC, 5 A
  • Compact size: 22.5 mm width
  • DIN Rail mounting for easy installation
  • Protected with IP20 rating
  • Complies with ISO 13849 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Expansion Timer
Brand
ABB
Series
TSR

Electrical

Supply Voltage
24V DC

Mechanical

Housing Colour
Yellow
Housing Material
PA66 with 25% fiberglass (UL94 V0)

Dimensions & Physical Data

Height
120mm
Weight
0.207kg
Width
22.5mm

Environmental

Operating Temperature
-25°C to 65°C
IP Rating
IP20

Safety, Standards & Compliance

Safety Category
Cat. 4
Safety Integrity Level
SIL 3
Performance Level
PL e
