ABB TF42-0.23 Thermal Overload Relay 0.23A 690VAC 1A Fuse Type T

Product Code: TF42-0.23

  • Rated for 690 VAC and 0.55 A
  • Trip Class 10 with auto reset
  • Direct mounting, compact size
  • Operates in -25 to 60°C range
  • Meets IEC/EN & UL standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Thermal Overload Relays
Brand
ABB

Electrical

Max. Operational Voltage
Main Circuit 600 V AC
Suitable for Single Phase / Three Phase
Yes
Thermal Current Setting Range
0.17 ... 0.23 A
Trip Class
10

Dimensions & Physical Data

Depth
70.5 mm
Height
88.3 mm
Weight
0.13 kg
Width
45 mm

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 60947-5-1 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L

Accessories & Additional Information

Suitable Product Range
AF09 AF12 AF16 AF26 AF30 AF38

Documents

IPD Product Catalogue V17
