ABB POLIM-C-3.5ND Surge Arrester 10.3kA 10kA 3.5kV Moulded Silicone Grey

Product Code: POLIM-C-3.5ND

  • Rated for 3.5 kV and 10 kA
  • Complies with IEC 60099-4 standards
  • Durable moulded silicone material
  • Operates in -60 to 40°C environments
  • Lightning impulse current of 10.3 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester
Brand
Hitachi Energy
Series
POLIM-C ND
Application
Devices in DC installations, Power electronics, Converter, Railway applications: fixed installations

Electrical

Short Circuit Current Rating
20kA
Nominal Discharge Current Inom (8/20µs)
10kA
Max. Continuous Operating Voltage
3.50 kV DC

Dimensions & Physical Data

Height
115mm

Environmental

Operating Temperature
-60°C to 40°C

Documents

IPD Product Catalogue V17
