ABB NFZB44E21 Contactor Relay 20-60VDC 4NO 50/60Hz

Product Code: NFZB44E21

  • Rated Voltage: 20-60 VDC
  • Contact Configuration: 4NO
  • Mounts on 35 x 15 mm Rail
  • IP20 Protection Rating
  • Operational Temp: -40 to 70°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Contactor Relays
Brand
ABB

Electrical

No. of N/C Contacts
4
No. of N/O Contacts
4
Rated Control Supply Voltage (Us)
50 Hz 24 ... 60V 60 Hz 24 ... 60V DC Operation 20 ... 60V
Rated Operational Current AC-15 (Ie)
(690V) 2A
Rated Frequency
50/60Hz
No. of Poles
4NO/4NC

Dimensions & Physical Data

Depth
86mm
Height
86mm
Weight
0.37kg
Width
45mm

Environmental

Ambient Temperature
-40°C to 70°C

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60335-2-40 LZGH2 A2L, UL 60947-5-1, CSA C22.2 No. 60335-2-40 LZGH2 A2L, CSA C22.2 No. 60947-5-1, IEC 60077-1 (applicable parts), IEC 60077-2 (applicable parts), EN 50155 (applicable parts), TR CU 001/2011, IEC 61373, For compliance confirmation on applicable parts based on your application and combination, please consult your ABB sales representatives.

Documents

IPD Product Catalogue V17
