ABB MS132-16 Manual Motor Starter 7.5kW 250V 16A

Product Code: MS132-16

  • Rated for 250 V, 16 A applications
  • Compact size: 45 mm width
  • IP20 protection rating
  • Rotary handle actuator for easy operation
  • High breaking capacity of 100 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Manual motor starter
Brand
ABB

Electrical

Thermal Current Setting Range
10.0 ... 16.0 A
Switch Type
Thermal and electromagnetic

Dimensions & Physical Data

Depth
86.55 mm
Height
97.8 mm
Weight
0.310 kg
Width
45 mm

Environmental

Ambient Temperature
Operation open compensated: -25 ... +60 °C

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1; IEC/EN 60947-2; IEC/EN 60947-4-1; UL 60947-1; UL 60947-4-1

Documents

IPD Product Catalogue V17
