ABB MPJLO430 Momentary Joystick Operator Switch 35 mm Mounting Hole 3NO+0NC

Product Code: MPJLO430

  • Illuminated selector switch with yellow LED
  • Wide voltage range: 110-130 VDC
  • High protection: IP20, IP66, IP67, IP69K
  • Versatile screw clamp connections
  • Operates in -25 to 70°C environments
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Joystick Operator Switch
Brand
ABB
Series
Modular plastic

Electrical

No. of N/C Contacts
0
No. of N/O Contacts
3
Terminal Type
Screw Connection
No. of Directions
8
Contact Block Thermal Current (Ith)
10 A
Contact Block Rated Current (Ie)
AC: 8 A (120 V), 6 A (230 V) DC:5 A (24 V)

Mechanical

No. of Positions
4
Switch Colour
Black
Switch Material
Plastic
Switching Function
Momentary

Dimensions & Physical Data

Length
134.6 mm

Environmental

IP Rating
IP66, 67, 69K

Documents

IPD Product Catalogue V17
