ABB Contact Block MCB-02 2NO+2NC Modular plastic

Product Code: MCB-02

  • Supports 690 VAC/VDC, 50/60 Hz operations
  • Compact size: 20mm W x 44mm H x 28mm D
  • IP20 protection for safe use
  • Operates in -25 to 70°C environments
  • Screw terminals with front mounting
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Contact Block
Brand
ABB
Series
Modular plastic

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Rated Current (In)
DC: (24 V) 5 A, (125 V) 0.55 A AC: (230 VAC) 6 A, (120 V) 8 A
Terminal Type
Screw Terminals
Rated Thermal Current (Ith)
10:00 AM

Mechanical

Contact Block Colour
Sliver

Documents

IPD Product Catalogue V17
