ABB LS72P98B11-A Limit Switch W/Ring Roller 57mm W

Product Code: LS72P98B11-A

  • Rated for 6A current
  • IP65 protection against dust and water
  • Operates from -25 to 70°C
  • Compact size: 33x57x118 mm
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Limit Switch
Brand
ABB

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Current (In)
10 A
Rated Voltage (Ur)
500 V
Terminal Type
2 x M16x1.5 (Side)

Mechanical

Actuator Type
pull action ring
Housing Material
Plastic

Dimensions & Physical Data

Depth
33 mm
Height
118 mm
Weight
0.132 kg
Width
57 mm

Environmental

IP Rating
IP67
Ambient Temperature
Operation -25 ... +70 °C

Documents

IPD Product Catalogue V17
