ABB LC36STE Load Center 36 -Module 3 -Row Plastic Clear Surface Mount IP40

Product Code: LC36STE

  • Polycarbonate load centre, 100 A capacity
  • Supports up to 36 poles
  • Surface mounting design
  • Clear plastic for visibility
  • IP40 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Load Center
Brand
ABB

Electrical

Rated Insulation Voltage (Ui)
1000V AC
Rated Current (In)
100A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
415V AC
Earth Terminal Block
Include
Neutral Terminal Block
Include
No. of Poles
36P (18 mm pitch)

Mechanical

DIN Rail
3-Row
Door Colour
Smoked transparent
Housing Colour
RAL 9010
Housing Material
High impact ABS
Mounting
Surface mount
No. of Rows
3

Dimensions & Physical Data

Depth
100mm
Height
473mm
Width
305mm

Documents

IPD Product Catalogue V17
