ABB GSH201C40A30 Residual Current Breaker with Overcurrent 6 kA 1P+N-P 30mA 40A C-Curve TypeA DIN Rail Mount IP20

Product Code: GSH201C40A30

  • Rated for 40 A at 230/240 VAC
  • Compact size: 35 mm width
  • IP20 protection rating
  • Type A residual current detection
  • DIN Rail mounting capability
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Residual Current Circuit Breakers With Overcurrent Protection RCBO
Brand
ABB
Series
GSH201

Electrical

No. of Poles (Total)
1P+N
Rated Current (In)
40A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
230/240V AC
Trip Curve
C
Terminal Type
Cage
Residual Current Type
Type A
Rated Residual Current
30mA
Electrical Life
10000 cycle
Mechanical Life
20000 cycle

Dimensions & Physical Data

Depth
69mm
Height
85mm
Weight
0.172kg
Width
35mm
Width in No. of Modular Spacing
2

Environmental

Storage Temperature
-40°C to 70°C
Operating Temperature
-25°C to 55°C
IP Rating
Open air IP20; Enclosure with cover IP40

Safety, Standards & Compliance

Standards and Approvals
IEC 61009-1; GB/T 16917.1; AS/NZS 61009.1
