ABB GSH201C25A30 Residual Current Breaker with Overcurrent 6 kA 1P+N-P 30mA 25A C-Curve TypeA DIN Rail Mount IP20

Product Code: GSH201C25A30

  • 25A rated current for reliable protection
  • Operates at 230/240 VAC voltage
  • Compact design: 35mm width, DIN rail mount
  • Complies with IEC & AS/NZS standards
  • IP20 protection against solid objects
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Residual Current Circuit Breakers With Overcurrent Protection RCBO
Brand
ABB
Series
GSH201

Electrical

No. of Poles (Total)
1P+N
Rated Current (In)
25A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
230/240V AC
Trip Curve
C
Terminal Type
Cage
Residual Current Type
Type A
Rated Residual Current
30mA
Electrical Life
10000 cycle
Mechanical Life
20000 cycle

Dimensions & Physical Data

Depth
69mm
Height
85mm
Weight
0.171kg
Width
35mm
Width in No. of Modular Spacing
2

Environmental

Storage Temperature
-40°C to 70°C
Operating Temperature
-25°C to 55°C
IP Rating
Open air IP20; Enclosure with cover IP40

Safety, Standards & Compliance

Standards and Approvals
IEC 61009-1; GB/T 16917.1; AS/NZS 61009.1
