Specifications

Product Type

Installation Contactors

Brand

ABB

No. of N/C Contacts 1	No. of N/O Contacts 3	No. of Poles (Total) 4
Rated Control Supply Voltage (Us) 220 V DC400 V AC	Rated Operational Current AC-1/AC7a (Ie) 63	Rated Frequency 50/60 Hz

Depth 65 mm	Height 85 mm	Weight 0.405 kg
Width 54 mm

Ambient Temperature

-25 ... +55 °C

Standards and Approvals

IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 61095

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe) 14.5 kW	Rated Operational Power AC-1/AC7a 400V 3 Phase (Pe) 43.6 kW	Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe) 5 kW
Rated Operational Power AC-3/AC7b 400V 3 Phase (Pe) 15 kW	Rated Operational Current AC-3/AC7b (le) 230 V1 phase 30 A

ABB ESB6331N06 Installation Contactor 63A 5kW 400VAC Screw DIN Rail Mount
