ABB ESB4031N06 Installation Contactor 4P 3NO+1NC 40A 3.7kW 400VAC DIN Rail Mount

Product Code: ESB4031N06

  • Suitable for 400 VAC, 40 A applications
  • Operates on both AC/DC voltage types
  • Compact design: 54mm wide, DIN rail mount
  • Contact config: 1NC+3NO for versatile use
  • IP20 protection ensures safe operation
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
DIN Contactors
Brand
ABB

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
3
Rated Control Supply Voltage (Us)
230V
Rated Operational Current AC-1/AC7a (Ie)
(NC) 30A; (NO) 40A
Rated Operational Current AC-3/AC7b (Ie)
(230V) NO 22A; (400V) NO 22A
Rated Frequency
Control Circuit 400Hz; 50Hz/60Hz
No. of Poles
3NO/1NC

Dimensions & Physical Data

Depth
65mm
Height
85mm
Weight
0.405kg
Width
54mm

Environmental

Ambient Temperature
-25°C to 55°C

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 61095 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L

Other

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)
NC 6.9kW; NO 9.2kW
Rated Operational Power AC-1/AC7a 400V 3 Phase (Pe)
NO 27.7kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)
NO 3.7kW
Rated Operational Power AC-3/AC7b 400V 3 Phase (Pe)
NO 11kW

Documents

IPD Product Catalogue V17
