ABB ESB4020N01 Installation Contactor 2P 40A 3.7kW 400VAC Screw DIN Rail Mount

Product Code: ESB4020N01

  • 40A rated current for robust performance
  • Suitable for both AC/DC operation
  • Compact design: 54mm width, 85mm height
  • DIN rail mounting for easy installation
  • IP20 protection against solid objects
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
DIN Contactors
Brand
ABB

Electrical

No. of N/C Contacts
0
No. of N/O Contacts
2
Rated Control Supply Voltage (Us)
24V
Rated Operational Current AC-1/AC7a (Ie)
(NO) 40A
Rated Operational Current AC-3/AC7b (Ie)
(230V) NO 22A
Rated Frequency
Control Circuit 400Hz; 50Hz/60Hz
No. of Poles
2NO

Dimensions & Physical Data

Depth
65mm
Height
85mm
Weight
0.37kg
Width
54mm

Environmental

Ambient Temperature
-25°C to 55°C

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 61095 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L

Other

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)
NO 9.2kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)
NO 3.7kW
