ABB ESB2530N06 Installation Contactor 3P 25A 1.3kW 400VAC Screw DIN Rail Mount

Product Code: ESB2530N06

  • Suitable for 400 VAC, 25 A applications
  • Operates on both AC/DC voltage
  • Compact size: 36mm width, DIN rail mount
  • IP20 protection for indoor use
  • Screw terminals ensure secure connections
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
DIN Contactors
Brand
ABB

Electrical

No. of N/C Contacts
0
No. of N/O Contacts
3
Rated Control Supply Voltage (Us)
230V to 240V
Rated Operational Current AC-1/AC7a (Ie)
(NO) 25A
Rated Operational Current AC-3/AC7b (Ie)
(230V) NO 9A; (400V) NO 9A
Rated Frequency
Control Circuit 400Hz; 50Hz/60Hz
No. of Poles
3NO

Dimensions & Physical Data

Depth
65mm
Height
85mm
Weight
0.23kg
Width
36mm

Environmental

Ambient Temperature
-25°C to 55°C

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 61095 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L

Other

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)
NO 5.8kW
Rated Operational Power AC-1/AC7a 400V 3 Phase (Pe)
NO 17.3kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)
NO 1.3kW
Rated Operational Power AC-3/AC7b 400V 3 Phase (Pe)
NO 4kW

Documents

IPD Product Catalogue V17
