Products

ABB ESB2504N03 Installation Contactor 4P 4NC 25A 400VAC Screw DIN Rail Mount

Product Code: ESB2504N03

  • 400 VAC rated voltage, 25 A current
  • 4NC contact configuration for secure connections
  • Compatible with AC/DC operating voltages
  • Compact design: 36mm width, 85mm height
  • IP20 protection for safe indoor use
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
DIN Contactors
Brand
ABB

Electrical

No. of N/C Contacts
4
No. of N/O Contacts
0
Rated Control Supply Voltage (Us)
48V
Rated Operational Current AC-1/AC7a (Ie)
(NC) 25A
Rated Operational Current AC-3/AC7b (Ie)
(230V) NC 6A
Rated Frequency
Control Circuit 400Hz; 50Hz/60Hz
No. of Poles
4NC

Dimensions & Physical Data

Depth
65mm
Height
85mm
Weight
0.245kg
Width
36mm

Environmental

Ambient Temperature
-25°C to 55°C

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 61095 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L

Other

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)
NC 5.8kW
Rated Operational Power AC-1/AC7a 400V 3 Phase (Pe)
NC 17.3kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)
NC 0.9kW
Rated Operational Power AC-3/AC7b 400V 3 Phase (Pe)
NC 2.7kW

Documents

IPD Product Catalogue V17
