ABB ESB2011N14 Installation Contactor 2P 1NC 1NO 20A 250VAC Screw DIN Rail Mount

Product Code: ESB2011N14

  • Compact DIN rail mount design
  • Handles up to 20 A current
  • Dual voltage operation: AC/DC
  • Secure screw terminal connections
  • Complies with IEC/EN standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
DIN Contactors
Brand
ABB

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Control Supply Voltage (Us)
12V
Rated Operational Current AC-1/AC7a (Ie)
(NO/NC) 20A
Rated Operational Current AC-3/AC7b (Ie)
(230V) NO/NC 9A
Rated Frequency
Control Circuit 400Hz; 50Hz/60Hz
No. of Poles
1NO/1NC

Dimensions & Physical Data

Depth
65mm
Height
85mm
Weight
0.14kg
Width
18mm

Environmental

Ambient Temperature
-25°C to 55°C

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 61095 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L

Other

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)
NO/NC 4.6kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)
NO/NC 1.3kW
