ABB ESB1611N06 Installation Contactor 2P 16A 0.9kW 250VAC Screw DIN Rail Mount

Product Code: ESB1611N06

  • Compact 18mm width for space-saving installations
  • Operates on both AC and DC voltages
  • Rated for up to 16 A at 250 VAC
  • Features 1NC+1NO contact configuration
  • IP20 protection with screw terminals
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
DIN Contactors
Brand
ABB

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
No. of Poles (NO/NC)
1NO/1NC
Rated Control Supply Voltage (Us)
230 V
Rated Operational Current AC-1/AC7a (Ie)
(NO/NC) 16 A
Rated Operational Current AC-3/AC7b (Ie)
(230 V) NO/NC 6 A
Rated Frequency
Control Circuit 400 Hz; 50 Hz/60 Hz

Dimensions & Physical Data

Depth
65 mm
Height
85 mm
Weight
0.14 kg
Width
18 mm

Environmental

Ambient Temperature
-25 ... +55 °C

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 61095 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L

Other

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)
NO/NC 3.7 kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)
NO/NC 0.9 kW
