ABB DSE203NMD25A30 Residual Current Circuit Breaker with Overcurrent Protection 10 kA 3P+N-P 30mA 25A C-Curve TypeA IP20

Product Code: DSE203NMD25A30

  • Rated for 25 A current
  • Supports 400/415 VAC voltage
  • Offers IP20 protection
  • Complies with IEC & AS/NZS standards
  • Handles short circuit up to 10kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Residual Current Circuit Breakers With Overcurrent Protection RCBO
Brand
ABB
Series
DSE203N M

Electrical

No. of Poles (Total)
3P+N
Rated Impulse Withstand Voltage (Uimp)
4kV
Rated Insulation Voltage (Ui)
500V AC/DC
Power Loss
12.81W
Rated Current (In)
25A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
400/415V AC
Trip Curve
D
Terminal Type
Pillar terminals
Residual Current Type
Type A
Rated Residual Current
30mA
Switching Neutral
No
Electrical Life
10000 cycle
Mechanical Life
20000 cycle

Mechanical

Conductor Cross Section Flexible
1mm² to 16mm²
Conductor Cross Section Solid Core
1mm² to 25mm²
Housing Type
Insulation group I

Dimensions & Physical Data

Depth
71.6mm
Height
117.5mm
Weight
0.549kg
Width
53.4mm
Width in No. of Modular Spacing
3

Environmental

Rated Surrounding Temperature Without Derating
30°C
Pollution Degree
2
Storage Temperature
-25°C to 70°C
Operating Temperature
-5°C to 55°C
IP Rating
IP20

Safety, Standards & Compliance

Standards and Approvals
IEC 61009-1; IEC 61009-2-2; AS/NZS 61009-1
