Products

ABB DSE203NMD20A100 Residual Current Circuit Breaker with Overcurrent Protection 10 kA 3P+N-P 0.1A 20A C-Curve TypeA IP20

Product Code: DSE203NMD20A100

  • 20 A RCBO with 3P+N configuration
  • Supports 400/415 VAC, 50/60 Hz
  • High short circuit capacity of 10kA
  • Complies with IEC and AS/NZS standards
  • Compact design: 53.4 mm width
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Residual Current Circuit Breakers With Overcurrent Protection RCBO
Brand
ABB
Series
DSE203N M

Electrical

No. of Poles (Total)
3P+N
Rated Impulse Withstand Voltage (Uimp)
4kV
Rated Insulation Voltage (Ui)
500V AC/DC
Power Loss
11W
Rated Current (In)
20A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
400/415V AC
Trip Curve
D
Terminal Type
Pillar terminals
Residual Current Type
Type A
Rated Residual Current
100mA
Switching Neutral
No
Electrical Life
10000 cycle
Mechanical Life
20000 cycle

Mechanical

Conductor Cross Section Flexible
1mm² to 16mm²
Conductor Cross Section Solid Core
1mm² to 25mm²
Housing Type
Insulation group I

Dimensions & Physical Data

Depth
71.6mm
Height
117.5mm
Weight
0.549kg
Width
53.4mm
Width in No. of Modular Spacing
3

Environmental

Rated Surrounding Temperature Without Derating
30°C
Pollution Degree
2
Storage Temperature
-25°C to 70°C
Operating Temperature
-5°C to 55°C
IP Rating
IP20

Safety, Standards & Compliance

Standards and Approvals
IEC 61009-1; IEC 61009-2-2; AS/NZS 61009-1

Documents

IPD Product Catalogue V17
