Specifications

Product Type

RCBO

Brand

ABB

Series

DSE203

No. of Poles (Total) 3P+N	Rated Impulse Withstand Voltage (Uimp) 4kV	Rated Insulation Voltage (Ui) 500V
Rated Current (In) 32A	Rated Frequency 50/60Hz	Rated Voltage (Ur) 400/415V AC
Trip Curve C	Terminal Type Pillar terminals	Residual Current Type Type A
Rated Residual Current 30mA	Electrical Life 10000	Mechanical Life 20000

Conductor Cross Section Flexible 16/16mm²	Conductor Cross Section Solid Core 25/25mm²	Housing Type Insulation group I, RAL 7035
Mounting DIN rail

Depth 72mm	Height 117.5mm	Weight 0.549kg
Width 53.4mm	Width in No. of Modular Spacing 4	Pole Width 18mm

Rated Surrounding Temperature Without Derating 30°C	Pollution Degree 2	Storage Temperature -40°C to 70°C
Operating Temperature -25°C to 55°C	IP Rating IP2X, IP4X

Standards and Approvals

IEC 61009-1, IEC 61009-2-2, AS/NZS 61009.1

Rated Short-Circuit Breaking Capacity (Icn) acc. To IEC/EN 61009-1

6kA

ABB DSE203NC32A30 Residual Current ACB 6 kA 3P+N-P 30mA 32A C-Curve TypeA Chassis Mounting IP20
