ABB CT-MFD.21 Time Relay 2CO SPDT Contact 12-240VAC/DC 4A Screw Terminal

Product Code: CT-MFD.21

  • Wide voltage range: 12-240 VAC/VDC
  • Flexible timing: 0.05 s to 100 hr
  • Compact design: 17.5 mm width
  • Dual mounting options on DIN rail
  • Robust protection: IP20, IP50 rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Time Relay
Brand
ABB
Series
CT

Electrical

Rated Control Supply Voltage (Us)
12V to 240V AC/DC
Rated Insulation Voltage (Ui)
Input Circuit / Output Circuit 300V Output Circuit 1 / Output Circuit 2 300V
Rated Operational Voltage (Ue)
Auxiliary Circuit 250V DC
Rated Operational Current AC-15 (Ie)
(230V) 3A
Timing Range
0.05 s ... 100 h
Output Type
2 C/O Contacts
Rated Frequency
50 / 60Hz DC
Terminal Type
Screw Terminals
Rated Operational Current AC-12 (Ie)
(230V) 5A
Rated Operational Current DC-12 (Ie)
(24V) 5A
Rated Operational Current DC-13 (Ie)
(24V) 1A
Timer Relay Type
ON-Delay OFF-Delay Impulse ON Impulse OFF Flasher Starting with ON Flasher Starting with OFF Pulse Former
Short-Circuit Protective Devices
Output Circuit NC-F Type Fuses 6 A Output Circuit NO-F Type Fuses 6 A

Dimensions & Physical Data

Depth
63mm
Height
80mm
Weight
0.066kg
Width
17.5mm

Environmental

Storage Temperature
-40°C to 85°C
Operating Temperature
-25°C to 60°C
IP Rating
IP50
