ABB CT-MFD.12 Time Relay 1CO SPDT Contact 24-240VAC 24-48VDC 4A Screw Terminal

Product Code: CT-MFD.12

  • Versatile voltage: 24-240 VAC, 24-48 VDC
  • Compact design: 17.5 mm width, 70 mm height
  • Wide operating time: 0.05 s to 100 hr
  • Reliable protection: IP20/IP50 rated
  • Easy DIN rail mounting options
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Time relay
Brand
ABB
Series
CT

Electrical

Rated Control Supply Voltage (Us)
24 ... 240 V AC 24 ... 48 V DC
Rated Insulation Voltage (Ui)
Input Circuit / Output Circuit 300 V
Rated Operational Current AC-15 (Ie)
(230 V) 3 A
Rated Operational Voltage (DC)
Auxiliary Circuit 250 V
Output Type
1 C/O (SPDT) Contact
Rated Frequency
50 / 60 Hz DC
Terminal Type
Screw Terminals
Rated Operational Current AC-12 (Ie)
(230 V) 6 A
Rated Operational Current DC-12 (Ie)
(24 V) 6 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A
Timer Relay Type
ON-Delay OFF-Delay Impulse ONImpulse OFF Flasher Starting with ON Flasher Starting with OFF Pulse Former
Time Range
0.05 s ... 100 h
Short-Circuit Protective Devices
Output Circuit NC-F Type Fuses 6 A Output Circuit NO-F Type Fuses 10 A

Dimensions & Physical Data

Depth
63 mm
Height
70 mm
Weight
0.053 kg
Width
17.5 mm

Environmental

Storage Temperature
-40 ... +85 °C
Operating Temperature
-20 ... +60 °C
IP Rating
IP50

Documents

IPD Product Catalogue V17
