ABB CPE24/0.75 CP-E Power Supply 1PH 90-264VAC 24VDC 0.75A 18 Watt DIN Rail Mount IP20

Product Code: CPE24/0.75

  • Compact size: 22.5 mm width
  • Wide voltage range: 90-264 VAC, 24 VDC
  • High protection: IP20 rating
  • Efficient DIN rail mounting
  • Operates from -20 to 70°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Supply
Brand
ABB
Series
CP - E

Electrical

Input Voltage
90 ... 132 V AC / 180 ... 264 V AC / 212 ... 375 V DC
Output Current - Nominal
0.75A
Output Power
18W
Output Voltage - Nominal
24V DC
Output Voltage - Range
21.6V to 28.8V DC
Efficiency
0.77
Terminal Type
Screw Terminal

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
114mm
Height
90mm
Width
22.5mm

Environmental

Approvals / Conformity
ANSI/ISA-12.12 CAN/CSA C22.2 No.107.1 CAN/CSA C22.2 No.213 CAN/CSA C22.2 No.60950 IEC/EN 63000 IEC 60950-1 IEC/EN 61000-6-2 IEC/EN 61000-6-3 UL 508 UL 60952
Operating Temperature
Operation -20 ... +70°C
IP Rating
Housing IP20 Terminals IP20
