ABB CE3T-10R-02 Compact Emergency-Stop button 30 mm 0NO+2NC

Product Code: CE3T-10R-02

  • Pushbutton with amber colour
  • Operates at 230 VAC
  • Rated current of 0.0105 A
  • Temperature range: -25 to 50°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Emergency Stop Button
Brand
ABB
Series
Compact

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
0
Illumination
Non-illuminated
Rated Current (In)
AC-15: (240V) 2A,DC-13: (24V) 0.3A, (125V) 0.2A
Rated Voltage (Ur)
AC-15: 230V,DC-13: 24V, 125V
Terminal Type
Screw terminals

Mechanical

Pushbutton Colour
Red
Pushbutton Material
Steel, Polycarbonate and Polyamide
Pushbutton Type
Mushroom
Unlocking Method
Twist release

Dimensions & Physical Data

Button Diameter (mm)
30mm

Environmental

IP Rating
IP67IP69IP69K
