ABB AFS580301271 Safety Contactor 3P 50A 60A 355kW 1000VAC 3NO

Product Code: AFS580301271

  • Rated for up to 1000 VAC, ensuring high voltage handling.
  • Supports 50 A and 60 A current ratings.
  • Features a 3NO contact configuration.
  • Compact design with IP20 protection rating.
  • Operates in -40 to 70°C storage temperatures.
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Contactor
Brand
ABB

Electrical

Rated Control Supply Voltage (Us)
250V to 500V AC/DC
Rated Operational Current AC-1 <= 690V (Ie)
800A
Rated Operational Current AC-1 1000V (Ie)
800A
Rated Operational Current AC-3 1000V (Ie)
250A
Rated Operational Current AC-3 400V (Ie)
580A
Rated Operational Current AC-3 690V (Ie)
500A
Rated Operational Power AC-3 1000V (Pe)
355kW
Rated Operational Power AC-3 400V (Pe)
315kW
Rated Operational Power AC-3 690V (Pe)
500kW
Rated Frequency
50/60Hz
No. of Poles
3P
No. of Auxiliary Contacts
3

Dimensions & Physical Data

Depth
242mm
Height
283mm
Weight
10kg
Width
210mm

Environmental

Ambient Temperature
-40°C to 70°C

Safety, Standards & Compliance

Standards and Approvals
IEC 60529, IEC 60947-1, EN 60529
