ABB AFS305301213 Safety Contactor 3P 305A 160kW 100-250VAC 1NO+2NC

Product Code: AFS305301213

  • Supports 100-250 VAC, 305 A
  • Operates at 50/60 Hz frequency
  • Impulse withstand voltage: 8 kV
  • Contact config: 1NO+2NC
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Contactor
Brand
ABB

Electrical

No. of Poles (Total)
3P
Rated Control Supply Voltage (Us)
100V to 250V AC/DC
Rated Operational Current AC-1 <= 690V (Ie)
(690V) 40 °C 500A
Rated Operational Current AC-3 400V (Ie)
(415V) 60 °C 305A
Rated Operational Current AC-3 690V (Ie)
(690V) 60 °C 290A
Rated Operational Power AC-3 1000V (Pe)
(1000V) 185kW
Rated Operational Power AC-3 400V (Pe)
(415V) 160kW
Rated Operational Power AC-3 690V (Pe)
(690V) 250kW
Rated Frequency
50/60Hz
No. of Auxiliary Contacts
1 NO + 2 NC

Dimensions & Physical Data

Depth
180mm
Height
225mm
Weight
4kg
Width
140mm

Environmental

Operating Temperature
-25 to 50 °C (Fitted with Thermal O/L Relay)

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-1, IEC/EN 60947-4-1

Documents

IPD Product Catalogue V17
