VSD ACS880 5.5KW 12.6A IP55 WITH BLUETOOTH CONTROL PANEL ACS880-01-12A6-3+B056+E200+P90

Product Code: 88001012510

  • Rated for 380-415 VAC, 10 A
  • IP55 protection for harsh environments
  • Compact wall mount design
  • Operates in -15 to 40°C range
  • Complies with CE, EMC, ATEX standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Machinery Drives
Brand
ABB

Electrical

No. of Input Phases
3-phase
Nominal Input Voltage
380V to 415V
Normal Duty Amps
12.6A
Normal Duty kW
5.5kW
Heavy Duty Amps
9.4A
Heavy Duty kW
4kW

Mechanical

Frame Size
R3
Control Panel (Keypad)
Yes

Dimensions & Physical Data

Depth
226mm
Height
409mm
Weight
6kg
Width
155mm

Environmental

Operating Temperature
Maximum 40°C
IP Rating
IP55

Safety, Standards & Compliance

Standards and Approvals
UNSPSC: 39122001

Documents

IPD Product Catalogue V17
