ABB 3AXD50000814558 Variable Speed Machinary Drive W/ CP 22kW 45A IP20 3PH

Product Code: 3AXD50000814558

  • Operates at 480 VAC and 45 A
  • Rated power of 22 kW
  • Compact size: 260x240x179 mm
  • IP20 protection rating
  • Includes control element & PC connection
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Main

Product Type
Variable speed drive
Brand
ABB
Series
ACS180

Electrical

No. of Analog Inputs
2
No. of Phases
3-phase input / 3-phase output
Rated Current
50 A
Rated Power
22 kW
Rated Voltage
3-phase 380 ... 480 V AC

Mechanical

Mounting Type
Cabinet mounted

Dimensions

Depth
178 mm
Height
240 mm
Width
260 mm

Environmental

IP Rating
IP20
Ambient Temperatures
-10 ... +50 °C

Standards and Approvals

Standards and Approvals
CE; EN 61800-5-1; EN 61800-5-2; EN 61800-3; RoHS; UL; cUL
