ABB 2CTB815710R3000 Surge Protective Device 12.5kA 2-P 80kA 400/690V Plug-In IP20

Product Code: 2CTB815710R3000

  • Rated for 400/690 V, 80 kA current
  • Plug-in connection for easy setup
  • IP20 protection, DIN rail mounting
  • Compact size: 53.4mm W x 95.8mm H x 76.7mm D
  • Protects systems from transient overvoltage
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Qs
Brand
ABB
Application
To protect the systems against the transient overvoltage (lightning)

Electrical

Lightning Impulse Current Iimp (10/350µs)
12.5kA
Max. Backup Fuse
160A gG
Nominal Voltage
400V AC, 690V AC
Voltage Protection Level Up
1.9kV, 2kV
Max. Discharge Current Imax (8/20µs)
80kA
Short Circuit Current Rating
100kA
Alarm Contact
1 NO + 1 NC
Nominal Discharge Current Inom (8/20µs)
20kA
No. of Poles
2P
Max. Continuous Operating Voltage
440 V

Dimensions & Physical Data

Depth
76.7mm
Height
95.8mm
Width
53.4mm
No. of Modules Width
3

Environmental

IP Rating
IP20
