ABB 2CTB803973R1900 Surge Protective Device 6.25kA 1-P 80kA 400VAC Plug-In IP20

Product Code: 2CTB803973R1900

  • 400 VAC surge protector with 80 kA current rating
  • Plug-in connection for easy installation
  • Compact DIN rail mounting, IP20 protection
  • Protects systems from transient overvoltage
  • Slim design: 17.8 mm width, 88 mm height
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Qs
Brand
ABB
Application
To protect the systems against the transient overvoltage (lightning)

Electrical

Nominal Voltage
230V AC, 400V AC
Voltage Protection Level Up
1400V
Max. Discharge Current Imax (8/20µs)
80kA
Short Circuit Current Rating
100kA
Nominal Discharge Current Inom (8/20µs)
30kA
No. of Poles
1P
Max. Continuous Operating Voltage
275 V

Mechanical

Terminal Size
25 mm2

Dimensions & Physical Data

Depth
58mm
Height
88mm
Width
17.8mm
No. of Modules Width
1

Environmental

IP Rating
IP20

Documents

IPD Product Catalogue V17
