ABB 1SNA645034R2300 Interface Relay 6mm W Screw Terminal 5VDC R600

Product Code: 1SNA645034R2300

  • Operates at 5 VDC with 1CO SPDT config
  • Compact design: 6 mm wide, 67.5 mm high
  • Screw terminals for secure connections
  • Silver tin oxide contacts enhance durability
  • Complies with CAN/CSA, IEC/EN, UL standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Interface Relay
Brand
ABB
Series
R600

Electrical

Actuating Voltage
5V DC
No. of Change-Over Contacts
1
Electrical Connection
Screw terminals
Rated Current (In)
0.01A to 6A
Rated Voltage (Ur)
5V to 250V AC

Mechanical

Housing Material
UL 94 V0
Mounting
Din Rail

Dimensions & Physical Data

Depth
70mm
Height
67.5mm
Width
6mm

Environmental

IP Rating
IP20
Ambient Temperature
-40°C to 80°C

Documents

IPD Product Catalogue V17
