ABB 1SNA645016R2100 Interface Relay 6mm W Screw Terminal 115VAC/DC R600

Product Code: 1SNA645016R2100

  • Rated for 115 VAC/VDC applications
  • Compact 6 mm width design
  • Screw terminal connections
  • Silver tin oxide contact material
  • Complies with CAN/CSA, IEC/EN, UL standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Interface Relay
Brand
ABB
Series
R600

Electrical

Actuating Voltage
115V AC/DC
No. of N/O Contacts
1
Electrical Connection
Screw terminals
Rated Current (In)
0.01A to 6A
Rated Voltage (Ur)
5V to 250V AC

Mechanical

Housing Material
UL 94 V0
Mounting
Din Rail

Dimensions & Physical Data

Depth
70mm
Height
67.5mm
Width
6mm

Environmental

IP Rating
IP20
Ambient Temperature
-40°C to 80°C

Documents

IPD Product Catalogue V17
