ABB 1SNA645003R0500 Interface Relay 6mm W Screw Terminal 115VAC/DC R600

Product Code: 1SNA645003R0500

  • 115 VAC/VDC rated voltage
  • 1CO SPDT contact configuration
  • Compact size: 6mm width, 67.5mm height
  • Screw terminal connection
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Interface Relay
Brand
ABB
Series
R600

Electrical

Actuating Voltage
115V AC/DC
No. of Change-Over Contacts
1
Electrical Connection
Screw terminals
Rated Current (In)
0.01A to 6A
Rated Voltage (Ur)
5V to 250V AC

Mechanical

Housing Material
UL 94 V0
Mounting
Din Rail

Dimensions & Physical Data

Depth
70mm
Height
67.5mm
Width
6mm

Environmental

IP Rating
IP20
Ambient Temperature
-40°C to 80°C

Documents

IPD Product Catalogue V17
