ABB 1SDA100548R1 Switch Disconnector IP20 400A 4-P F Version 690/750VAC/DC

Product Code: 1SDA100548R1

  • Handles up to 400 A current
  • Compact size: 186x205x103.5 mm
  • Rated voltage: 690/750 VAC/VDC
  • IP20 protection for safety
  • 4-pole front connection
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Switch Disconnector
Brand
ABB
Series
SACE Tmax XT

Electrical

Position of Line Terminals
Front
Rated Impulse Withstand Voltage (Uimp)
8kV
Rated Insulation Voltage (Ui)
1000V
Rated Operating Voltage
690V
Rated Operational Current AC23-A (Ie)
400A
Rated Short Time Withstand Current (Icw)
5000A
Rated Uninterrupted Current (Iu)
400A
Power Loss
72.3W
Rated Current (In)
400A
Mechanical Life
20000 cycles
No. of Poles
4P

Dimensions & Physical Data

Depth
103.5mm
Height
205mm
Weight
5.6kg
Width
186mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60947-2, CE
