ABB 1SDA080843R1 Moulded Case Circuit Breaker 690/500VAC/VDC 20A 4-P 6kA 450A Front For: XT1N

Product Code: 1SDA080843R1

  • MCCB with 20 A rated current
  • 4-pole design for versatility
  • High breaking capacity of 6 kA
  • Front connection type for ease
  • Complies with IEC60947-2 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Automatic Circuit Breaker
Brand
ABB
Series
SACE Tmax XT
Application
Power Distribution

Electrical

Rated Insulation Voltage (Ui)
800V
Type of Protection Trip Unit
TM
Power Loss
5.4W
Rated Current (In)
160A
Trip Curve
TMF
Terminal Type
Front
Electrical Life
8000 cycles
Mechanical Life
25000 cycles
No. of Poles
4P

Dimensions & Physical Data

Depth
70mm
Height
130mm
Weight
1.3kg
Width
101.6mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60947-2

Other

Rated Ultimate Short Circuit Breaking Capacity (Icu) at 415 V, 50 Hz
36kA
Rated Service Short Circuit Breaking Capacity, (Ics) 690V AC
5kA
Rated Ultimate Short Circuit Breaking Capacity, (Icu) 690V AC
6kA
