<p>When selecting a Molded Case Circuit Breaker (MCCB) for your industrial or commercial application, it&#39;s crucial to focus on the technical specifications that ensure reliability and efficiency. This MCCB is designed with precision to meet the demands of modern electrical systems.</p><p>Rated at 100 A, this MCCB offers robust protection for your circuits, making it suitable for a wide range of applications. It operates efficiently within a rated voltage of 690 VAC and boasts an impressive rated insulation voltage of 1000 V. With a rated impulse withstand voltage of 8 kV, it provides excellent resilience against transient overvoltages.</p><p>The Ekip Dip LSI trip unit ensures precise control and protection by offering adjustable settings for long-time, short-time, and instantaneous tripping characteristics. This feature enhances the safety and flexibility needed in complex electrical installations.</p><p>This MCCB features four poles, which can be advantageous in three-phase systems where neutral protection is required. Its breaking capacity stands at 15 kA, ensuring reliable interruption performance during fault conditions.</p><p>Designed with user convenience in mind, it supports front connection type with bolt terminals. The main circuit connecting capacity ranges from 85 to 200 sq-mm, accommodating various conductor sizes typically used in industrial setups. Additionally, its IP20 degree of protection safeguards against ingress of solid foreign objects larger than 12 mm.</p><p>With dimensions optimized for space-saving installations—140 mm in width—and weighing just 3.5 kg, this MCCB integrates seamlessly into panelboards or switchgear assemblies without imposing excessive load or requiring extensive modifications.</p><p>Compliant with IEC60947-2 standards and approvals, it aligns with international safety requirements ensuring peace of mind regarding quality and performance benchmarks.</p><p>Given its power loss rating at only 4.2 W during operation combined with compatibility specifically designed for use with XT4H devices—this MCCB presents itself as both energy-efficient and versatile across multiple applications operating at standard frequencies between 50/60 Hz.</p><p>Overall—it’s engineered not just to protect but also enhance operational efficiency while maintaining rigorous safety protocols essential in today’s demanding environments.</p>
