ABB 1SDA068204R1 Fixed Part Withdrawable Circuit-Breaker 3-P 690/500VAC/DC 250A Extended Front For: XT4

Product Code: 1SDA068204R1

  • Rated for 250A current handling
  • Withstands impulse voltage up to 8kV
  • Insulation rated at 1000V
  • Supports both AC and DC voltages
  • Compatible with XT4 systems
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fixed Part
Brand
ABB
Series
Accessories for Tmax XT

Electrical

Max. Rated Operation AC Voltage (Ue)
690V AC
Rated Insulation Voltage (Ui)
1000V
Rated Current (In)
250A
Rated Frequency
50/60Hz
Terminal Type
Withdrawable Circuit-Breakers, Front Extended
No. of Poles
3P

Dimensions & Physical Data

Weight
1.5kg

Safety, Standards & Compliance

Standards and Approvals
IEC 60947-2, UL 489

Documents

IPD Product Catalogue V17
