ABB 1SDA067401R1 Moulded Case Circuit Breaker 690/500VAC/VDC 32A 4-P 25kA TMD 450A Front For: XT1C

Product Code: 1SDA067401R1

  • 32 A rated current, ideal for various applications
  • 25 kA breaking capacity ensures safety
  • Front connection with bolt terminals for easy install
  • Complies with IEC60947-2 standards
  • Compact width of 101.6 mm saves space
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Automatic Circuit Breaker
Brand
ABB
Series
SACE Tmax XT
Application
Power Distribution

Electrical

AC Power Loss Per Pole at In
2.1W
Long Time Overload Protection Adjustment Range
22.4 to 32 A
Max. Rated Operation AC Voltage (Ue)
690V AC
Position of Connection for Main Current Circuit
Front
Rated Insulation Voltage (Ui)
800V
Type of Protection Trip Unit
TM
Rated Current (In)
32A
Rated Frequency
50/60Hz
Trip Curve
TMD
Terminal Type
Bolt
Electrical Life
8000 cycles
Mechanical Life
25000 cycles
No. of Poles
4P

Dimensions & Physical Data

Depth
70mm
Height
130mm
Weight
1.4kg
Width
101.6mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60947-2

Other

Rated Ultimate Short Circuit Breaking Capacity (Icu) at 415 V, 50 Hz
25kA
Rated Service Short Circuit Breaking Capacity, (Ics) 690V AC
4kA
Rated Ultimate Short Circuit Breaking Capacity, (Icu) 690V AC
4kA
