ABB 100A 2P SWITCH DISCONNECTO OTDC100E11

Product Code: OTDC100E11

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
DC Switch - Disconnector
Brand
ABB
Series
OTDC
Application
Manufacturing, commercial buildings, HVAC

Electrical

Position of Line Terminals
Top In - Bottom Out Bottom In - Top Out
Rated Impulse Withstand Voltage (Uimp)
12kV
Rated Insulation Voltage (Ui)
1500V
Rated Operating Voltage
1000V DC
Rated Short Time Withstand Current (Icw)
10kA for 1 s; 5kA for 0.1 s
Power Loss
per pole 2W; total 4W
Rated Current (In)
100A
Special Functions
No
No. of Poles
2P

Dimensions & Physical Data

Depth
83.5mm
Height
176mm
Weight
1.2kg
Width
115.5mm

Environmental

Pollution Degree
3
IP Rating
Front IP20

Safety, Standards & Compliance

Standards and Approvals
IEC 60947-1, -3

Accessories & Additional Information

Included Components
Terminal bolt kit
